Precision Precast

Box Culvert Performs in New York City

[Photo by Frank Oudeman 2010©]

Figure 1 Photo shows completed Burling Slip “Imagination Playground” in Lower Manhattan, NYC in use by residents. One side of the figure-eight playground layout contains sand and the other side sports a water feature; the sand and water are reminders of the sea and shore elements of the historic seaport location.

[Photo by Frank Oudeman 2010©]

Figure 2 Hydrostatic testing of the precast culvert assembly was conducted by an independent agency at Garden State Precast’s New Jersey facility.

[Photo by Frank Oudeman 2010©]

[Photos courtesy of Garden State Precast (Fig. 3a) and Scott Lander, Hamilton Kent LLC (Fig. 3b)]

Figures 3a and 3b In combination with radius corners, the single-offset joint box culvert design offered the advantages of watertight gasket connections and reduced installation time for the contractor.

[Photos courtesy of Garden State Precast (Fig. 3a) and Scott Lander, Hamilton Kent LLC (Fig. 3b)]

[Photos courtesy of Scott Lander, Hamilton Kent LLC]

Figures 4a and 4b Photo with Scott Lander of Hamilton Kent illustrates the tight space for lowering the precast and the tongue-and- groove shoring with cross beams used to support the walls against the high water table and earth loads.

[Photos courtesy of Scott Lander, Hamilton Kent LLC]

[Line art courtesy: Rockwell Group]

Architectural drawing Designed in a ship-like shape, the new Imagination Playground is meant to be reminiscent of the site’s original port.

 The high water table beneath the historic South Street Seaport district of lower Manhattan at the site of the newly-opened Imagination Playground, provided an ideal case study for the watertightness of precast concrete box culvert combined-sewer system.

The Big Apple isn’t for everyone. Not many construction contractors are tough enough to compete in New York City (NYC). There are some national and international firms that will not work in NYC for a number of reasons, including multiple regulatory agencies; onerous permitting requirements; congested underground utilities; and last, but-certainly not least – notorious traffic.

Contractors who succeed in NYC need to be pretty savvy, like Garden State Precast, headquartered in New Jersey, who fabricated, tested and supplied the precast concrete box culvert tunnel system. This precast tunnel...
