Panel-to-panel connections for forming concrete structures

(10) US2018112399 A1

(57) A stay-in-place lining is provided for lining a structure fabricated from concrete. The lining comprises a plurality of panels connectable via complementary connector components on their longitudinal edges. Each panel comprises a first connector component on a first longitudinal edge thereof and a second (complementary) connector component on a second longitudinal edge thereof. The lining comprises at least one edge-to-edge connection between the first connector component of a first panel and the second connector component of a second panel, the edge-to-edge connection comprising a protrusion of the first panel extended into a receptacle of the second panel through a receptacle opening. The receptacle is shaped to prevent removal of the protrusion from the receptacle and the receptacle is resiliently deformed by the extension of the protrusion into the receptacle to thereby apply a restorative force to the protrusion to maintain the edge-to-edge connection.

(71) (CFS Concrete Forming Systems Inc (CA)

(73) RICHARDSON GEORGE DAVID [CA]; KRIVULIN SEMION

[CA]; FANG ZI LI [CA]
