Mold assembly for molding two concrete blocks and method of manufacturing concrete blocks

(10) US 2022/0314490 A1

(22) 20.06.2022

(43) 06.10.2022

(57) A mold assembly and method for molding two concrete blocks in face-to-face non-contacting relationship forms blocks having smooth front faces. The mold assembly includes a mold box having two mold cavities configured to form two blocks in face-to-face-non-contacting relationship. A common partition plate seperates the two mold cavities and opposite sides of the partition plate form the smooth front faces of the blocks. The two mold cavities are each configured to form a block having a raised front face with a beveled edge around its entire perimeter and a border around the entire perimeter of the beveled edge. The portions of the border at the top and the sides of the raised front face are curved and the portion of the border at the bottom of the raised front face is straight. A core bar is slidably inserted into the mold box beneath the bottom of the partition plate, and opposite sides of the core bar extend into and form the front bottom portions of the mold cavities.

(71) E. Dillon & Company, Swords Creek, VA (US)
