Prefabricated concrete floor slab assembly

(10) CN117468634

(22) 10.11.2023

(43) 30.01.2024

(57) The prefabricated concrete floor slab assembly comprises a slab body, clamping boxes, first supporting plates, supporting boxes and first supporting rods, the clamping boxes are installed on the inner wall of the slab body, the first supporting plates are installed on the inner wall of the slab body, the supporting boxes are installed on the inner wall of the slab body, the first supporting plates are installed on the inner wall of the slab body, and the first supporting boxes are installed on the inner wall of the slab body. And a first sleeve is mounted on the outer wall of the clamping box. By installing the first spring, the clamping box and the clamping rod, the effects of quickly installing the floor assembly and reducing manual labor are achieved, the second supporting rod moves to drive the first supporting rod to move, the first supporting rod moves to drive the first spring to move, the first spring moves to enable the first supporting rod to drive the clamping rod to move, and the clamping rod moves to pull up the floor assembly; the clamping head is placed into the clamping box through the clamping opening, the second supporting rod is loosened, the first spring pulls the first supporting rod to drive the clamping rod to be clamped into the second opening, the floor assembly is rapidly installed, manual labor is reduced, and the functions of rapidly installing the floor assembly and reducing the manual labor are achieved.

(71) Huaian Fan Zhi Sheng Yuan Da Building Industry Co., Ltd., CN
