Fabric concrete block and preparation method

(10) WO 2019/200970 A1

(22) 29.12.2018

(43) 24.10.2019

(57) Disclosed are a fabric concrete block and a preparation method therefor. The block comprises four L-shaped angle shafts (2) arranged to form edges and corners of a rectan­gular barrel, a fabric housing (1) fixed outside the L-shaped angle shafts (2) in a tensioned and winding manner to form a rectangular barrel-shaped structure, and a filler (5) filled inside the fabric housing (1). The preparation method comprises the following steps: 1. bonding
L-shaped angle shafts (2) to four edges of a core barrel (3) by means of a double-sided adhesive and applying a mixture of an epoxy resin and a curing agent to outer surfaces thereof, wrapping a fabric around the core barrel (3) once and bonding same on the L-shaped angle shafts (2), maintaining tension until the epoxy resin solidifies, and removing the core barrel (3) to com­plete the preparation of the fabric housing (1); 2. filling a filler into the fabric housing (1), and pressing and vibrating the filler to make same compact, so that the fabric is attached to an inner wall of a steel mould (4); and 3. curing the filler (5) until same is initially solidified, removing the steel mold (4), and continuing to cure the filler (5) until same is fully solidified.

(84) ARIPO (BW, GH, GM, KE, LR, LS, MW, MZ, NA, RW, SD, SL, ST, SZ, TZ, UG, ZM, ZW), RAE (AM, AZ, BY, KG, KZ, RU, TJ, TM), RA (AL, AT, BE, BG
