New battery mold with double capacity

Figure: BFT International

The two wings of the butterfly formwork are spread out on the floor of the production hall like a butterfly. Thus, reinforcement and mounting parts can be placed fast and easily

Figure: BFT International

The concrete layers are fixed above the reinforcement on the formwork surface so that the butterfly formwork can be transported reliably through the production hall after lifting out of the frame

Figure: BFT International

The butterfly formwork is placed into the frame of the battery mold, next to the other maximum six butterfly formwork units

Figure: BFT International

The butterfly formwork including reinforcement in the battery

Figure: BFT International

Interior views of a low-cost house built with precast concrete components made in the new battery mold of B.T. innovation

Figure: BFT International

The B.T.-Spannschloss turnbuckle connects floors, walls and ceilings of the low-cost house

Figure: BFT International

The new formwork system of B.T. innovation located in Magdeburg is compact and efficient. A field of application for the battery mold and the associated so-called butterfly formwork are low-cost housing projects in threshold countries or in series housing construction in Germany.

Like a butterfly spreading out its wings, the new formwork is lying on the floor of the production hall of B.T. innovation in Magdeburg – on the left a prepared steel formwork surface including reinforcement and mounting parts, on the right a likewise prepared steel formwork surface; two hinges at the center connect both sides measuring 6 x 2.40 m each.

When the hook of the indoor crane is traveling upwards, it is pulling at the center part with the two hinges and the formwork, which is actually called and sold by the supplier B.T. innovation under the memorable name “butterfly formwork”, is...
