H-shaped precast concrete element for the
construction of storage facilities

(10) EP4491833A1

(22) 12.07.2024

(43) 15.01.2025

(57) The present invention relates to a prefab concrete element for constructing side walls for storage facilities, comprising a horizontal floor slab, two side walls extending upwards from the floor slab, and a coupling beam, wherein the floor slab extends sideways over the entire length of the side walls in a transverse direction, wherein the coupling beam connects the two side walls to each other, wherein the coupling beam forms a walkway between the side walls and is arranged at such a distance from the top of the two side walls that the side walls form a railing, wherein the two side walls extend parallel and transverse to the floor slab, wherein the two side walls and the coupling beam form an H and wherein the prefab element ...

(71) CBS Beton nv, BE
